| Customization: | Available |
|---|---|
| Outer Diameter: | 25mm |
| Pore Size: | 0.1/0.2/0.45/1.0/3.0/5.0um |
| Quantity: | |
|---|---|
Filter Media | PES/ Nylon / PTFE / MCE / PVDF | |||||
Pore Size, μm | 0.1, 0.22, 0.45, 1.0, 3.0, 5.0 | |||||
Diameter | 13 mm | 20 mm | 25 mm | 33 mm | ||
Housing | PP/HDPE | ABS | PP/HDPE | |||
Filtration Area | 1.3 cm 2 | 3.1 cm 2 | 4.9 cm 2 | 8.5 cm 2 | ||
Maximum Operating Pressure | 5.2 bar | 3.5 bar | 5.2 bar | |||
Dimension | 16.0mm*23mm | 23mm*23.5mm | 28.0mm*24.3mm | 40.0mm*30.3mm | ||
Hold-up Volume | <100 μl | <150 μl | <250 μl | <350 μl | ||
Inlet | Female Luer Lock | Female Luer Lock | Female Luer Lock | Male Luer Unlock | Female Luer Lock | Female Luer Lock |
Outlet | Male Luer Unlock | Male Luer Lock | Male Luer Lock | Male Luer Unlock | Male Luer Unlock | Male Luer Unlock |
Flow Direction | Flow should enter from the inlet | |||||
Sterilization | Autoclave at 121°C at 1 bar for 20 minutes | |||||
Bacterial Endotoxins | < 0.25 EU/ml as determined by the LAL test | |||||
Filter Media | PES/ Nylon / PTFE / MCE / PVDF | |||||
Pore Size, μm | 0.1, 0.22, 0.45, 1.0, 3.0, 5.0 | |||||
Diameter | 13 mm | 20 mm | 25 mm | 33 mm | ||
Housing | PP/HDPE | ABS | PP/HDPE | |||
Filtration Area | 1.3 cm 2 | 3.1 cm 2 | 4.9 cm 2 | 8.5 cm 2 | ||
Maximum Operating Pressure | 5.2 bar | 3.5 bar | 5.2 bar | |||
Dimension | 16.0mm*23mm | 23mm*23.5mm | 28.0mm*24.3mm | 40.0mm*30.3mm | ||
Hold-up Volume | <100 μl | <150 μl | <250 μl | <350 μl | ||
Inlet | Female Luer Lock | Female Luer Lock | Female Luer Lock | Male Luer Unlock | Female Luer Lock | Female Luer Lock |
Outlet | Male Luer Unlock | Male Luer Lock | Male Luer Lock | Male Luer Unlock | Male Luer Unlock | Male Luer Unlock |
Flow Direction | Flow should enter from the inlet | |||||
Sterilization | Autoclave at 121°C at 1 bar for 20 minutes | |||||
Bacterial Endotoxins | < 0.25 EU/ml as determined by the LAL test | |||||
