PES Membrane
PES membrane is a highly microporous membrane composed of modified polyethersulfone that is a tough, durable, and temperature-resistant aromatic polymer.
PES membrane provides high flow rate, low extractables and greater mechanical strength than competitive membranes. This membrane is specifically designed for biological, analytical, electronic, pharmaceutical, beverage, and sterilizing filtration applications.
PES membrane is available in pore sizes ranging from 0.01 μm to 1.0 μm. It is inherently hydrophilic as standard, but can be made hydrophobic upon request. | Filter Membrane | Hydrophilic PES |
| Color | White |
| Filter Surface | Plain |
| Thickness, μm | 110~140 |
| Diameter | Disc: Φ13, Φ25, Φ47, Φ50, Φ60, Φ90, Φ100, Φ142, Φ150, Φ200, Φ250, Φ293, Φ300 |
| Pore Size, μm | 0.1, 0.22, 0.45, 0.65, 0.8, 1.2, 3.0 |
| Maximum Operating Pressure | Forward: 4.2 bar @ 23°C ; 1.5 bar @ 85 °C |
| pH | 1~14 |
| Flow Rate |
| 0.22 μm | ≥ 15 mL/min/cm 2 at 1 bar |
| 0.45 μm | ≥ 35 mL/min/cm 2 at 1 bar |
| Integrity Test -water bubble point at 23 °C |
| 0.22 μm | ≥ 3500 mbar |
| 0.45 μm | ≥ 2500 mbar |
FAQ: 1. Package Details: Plastic bags inside,carton outer.
2. OEM including what items?
Brand OEM. Part number OEM. Sizes and Structure OEM.
3. What is warranty?
Our warranty is 1 year. It means in the correct installation and normal using condition,if our goods meet any quality questions,we will re-produce for you again for free.
4. Can you offer sample to check the quality?
We offer FREE SAMPLES based on freight collect.
5. What about delivery time?
Order delivering time has relations with the order quantity, order models and packagings. Generally, it takes about 1-15days to get the order ready.
Shipping: Maritime; Railway; Air (DHL/UPS/TNT/FEDEX)
Company Profile: JiAn city QingFeng Filter Equipment Co., Ltd is a direct chinese manufacturer in industrial filtration and separation region since 2006year , producing and marketing micro filtration products for pharmaceutical, food and beverage, chemical and electronic industries and other related liquid and gas filtration industries, such as filter membrane, filter cartridges, filter housing.
Our factory has a full set of filter technology and filter production equipment (include quality monitoring equipment) which is imported from Japan. At the meantime, Our factory adhering to the technology advantage of CN-CA reinforced membrane( the important new product of 85 national torch plan) And Nylon reinforced membrane(the first Nylon creator).And our factory also the domestic leading technical level in producing reinforced PVDF membrane. The products and services we offer will provide world class quality.
