Composite Fiber Glass Filter Paper

Customization: Available
Type: 1/3/5/10/15/20/25um
Certification: SGS and ISO9001
Quantity:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button

Basic Info.

Model NO.
fiber glass filter paper
Material
Glass Fiber
Usage
Air/ Liquid/Powder/ Filter
Color
White
Thickness
0.50±0.02mm
Transport Package
Carton Packing
Specification
width have1000mm, can be customer-built
Trademark
QingFeng, OEM
Origin
China
HS Code
8421999000
Production Capacity
150000square Meter/Year

Product Description

                               Glass Fiber Membrane(GF)
Glass filter membrane is made from 100% glass fiber. With high flow rate and retention rate, could filter particles. GF membrane is higher filtration efficiency and stronger assimiative capacity than the other fiber material and artificial material

Product Characteristic:
1.      GF membrane is made from glass fiber, including binder free and binder
2.      High temperature resistance, tolerance under 500ºC(Grade GF10,tolerance under 180ºC)
3.      Be available for pre-filtration
4.      Excellent interception capacity due to Large surface area of GF membrane
5.      High folw rate
6.      Could decrease cost of filtration and previous resistance when substance difficult to filter or solvent high polluted
Typical Application:
1.      Efficient and conventional filtration
2.      Filtration of reagent
3.
Pre-filtration of membrane filter

CODE

Basic Weight
(g/Square )

Beta 200 Efficiency
(200β)
Pressure Drop
(pa)

Dust Holding Capacity
(g/Square meter)

Thickness
(mm)
QFU1 130±10 1 400 90
0.50±0.02

QFU3 130±10 3 150 90 0.50±0.02

QFU5

130±10 5 85 100 0.50±0.02

QFU10

130±10 10 50 115 0.50±0.02

QFU15

130±10 15 40 120 0.50±0.02

QFU20

130±10 20 30 120 0.50±0.02

QFU25

130±10 25 20 130 0.50±0.02
Composite Fiber Glass Filter Paper Composite Fiber Glass Filter Paper
Composite Fiber Glass Filter Paper Composite Fiber Glass Filter Paper
Composite Fiber Glass Filter Paper
