| Customization: | Available |
|---|---|
| Material: | Pes Membrane and PP |
| Usage: | Dust Filter, Liquid Filter, Air Filter |
| Quantity: | |
|---|---|
| Filter medium | Hydrophilc PES Filter membrane |
| Support layer | Polypropylene (PP) |
| Core & Cage | Polypropylene (PP) |
| End caps | Polypropylene (PP) |
| O-rings/Gasket | Silicone/EPDM/Viton |
| End connection | DOE,222,SOE,Code-7(226/Fin) |
| Sealing Technology | Thermal Bonding, No Adhesives |
| Removal Ratings(μm) | 0.1, 0.2, 0.45, 0.65,1.0(um) |
| Length | 5", 10", 20". 30", 40" |
| Outer Diameter | 68mm |
| Effective filtration area: | 0.6m2/10" |
| Max. operating temperature | 85ºC,0.05Mpa |
| Max. positive pressure | 0.42Mpa (25ºC) |
| Sterilizing temperature | Autoclaving 121ºC/30min |
| Others: special requirement of diameter and end caps can be customized | |
| Integrity test (minimum bubble point)(25ºC;95%isopropanol) | |
| 0.10 um >= 4000 mbar | |
| 0.20 um >= 3000 mbar | |
| 0.45 um >= 2000 mbar | |
| Filter medium | Hydrophilc PES Filter membrane |
| Support layer | Polypropylene (PP) |
| Core & Cage | Polypropylene (PP) |
| End caps | Polypropylene (PP) |
| O-rings/Gasket | Silicone/EPDM/Viton |
| End connection | DOE,222,SOE,Code-7(226/Fin) |
| Sealing Technology | Thermal Bonding, No Adhesives |
| Removal Ratings(μm) | 0.1, 0.2, 0.45, 0.65,1.0(um) |
| Length | 5", 10", 20". 30", 40" |
| Outer Diameter | 68mm |
| Effective filtration area: | 0.6m2/10" |
| Max. operating temperature | 85ºC,0.05Mpa |
| Max. positive pressure | 0.42Mpa (25ºC) |
| Sterilizing temperature | Autoclaving 121ºC/30min |
| Others: special requirement of diameter and end caps can be customized | |
| Integrity test (minimum bubble point)(25ºC;95%isopropanol) | |
| 0.10 um >= 4000 mbar | |
| 0.20 um >= 3000 mbar | |
| 0.45 um >= 2000 mbar | |
