| Customization: | Available |
|---|---|
| Material: | Glass Fiber and PP |
| Application: | Industry, Food and Beverage, Medicine, Textile, Metallurgy |
| Quantity: | |
|---|---|
| Materials of Construction | |
| Filter Media | Glass Fiber |
| Support and Drainage | PP |
| Core, Cage | PP |
| End Caps | PP |
| O-rings/Gasket | Silicone/EPDM/Viton |
| Sealing Technology | Thermal Bonding, No Adhesives |
| Dimensions | |
| Diameter | Φ68 |
| Length | 5 inch, 10 inch, 20 inch, 30 inch, 40 inch |
| Filtration Area, ft 2 | |
| ≥ 4.0 per 10-inch element | |
| Pore Size, μm | |
| 0.65, 1.0, 3.0, 5.0 | |
| Maximum Differential Pressure | |
| Forward: 4.2 bar @ 23 C; 1.5 bar @ 85 C | |
| Flow Rate & Pressure Drop , per 10-inch cartridge | |
| 0.65 μm | ≥ 28 L/min at 210 mbar |
| Particle Removal Efficiency (%) | |
| ≥ 90 | |
| Sanitization | |
| May be hot water sanitized for 30 cycles using purified water at 85 C for 30 min | |
| Materials of Construction | |
| Filter Media | Glass Fiber |
| Support and Drainage | PP |
| Core, Cage | PP |
| End Caps | PP |
| O-rings/Gasket | Silicone/EPDM/Viton |
| Sealing Technology | Thermal Bonding, No Adhesives |
| Dimensions | |
| Diameter | Φ68 |
| Length | 5 inch, 10 inch, 20 inch, 30 inch, 40 inch |
| Filtration Area, ft 2 | |
| ≥ 4.0 per 10-inch element | |
| Pore Size, μm | |
| 0.65, 1.0, 3.0, 5.0 | |
| Maximum Differential Pressure | |
| Forward: 4.2 bar @ 23 C; 1.5 bar @ 85 C | |
| Flow Rate & Pressure Drop , per 10-inch cartridge | |
| 0.65 μm | ≥ 28 L/min at 210 mbar |
| Particle Removal Efficiency (%) | |
| ≥ 90 | |
| Sanitization | |
| May be hot water sanitized for 30 cycles using purified water at 85 C for 30 min | |
