China Manufacturer SGS 0.2um 3.0 Micron PP Pleated 10 Inch Filter Cartridge for Water Treatment
Product Description
PP Pleated Filter Cartridge PP pleated filter cartridge is made of pleated polypropylene membrane, polypropylene non-woven fabrics and polypropylene cage. During the production, it is purity, free of surfactants, resins, binders and adhesives. It can be used for the liquid and gas prefiltration and clarification. Main Characteristics: 1. 100% high quality polypropylene material
2. Wide chemical compatibility
3. High flow rate
4. Low differential pressure
5. High dirt holding capacity
6. High nominal filtration precision
7. Long using life
8. Economical choice for the prefiltration and guard filtration before critical filtration
9. Board range of micron ratings
10. Suitable for various filtration
11. Meet the current FDA after cleaned and flushed with Pyrogen-free water Micron Rating(µm): 0.10 0.20 0.45 1.0 3.0 5.0 10.0 20.0 40.0 50.0 100.0 Typical Applications: 1. Pharmaceuticals, APIs, Biologics; Solvent; Compressed air filtration
2. Plating solutions, Ink
3. Fine Chemicals
4. Food & Beverages, Wine, Beer, Mineral Water
5. Semi-Conductor, LCD Display, Discs, R.O. prefiltration
6. Clarification of waste water treatment Specifications: | Filter medium | PP membrane |
| Support Layer | Polypropylene |
| Inner Core | Polypropylene |
| Outer Core | Polypropylene |
| Outer Diameter | 68mm |
| Inner Diameter | 33mm |
| Effective Filtration Area | ≥0.60m2 |
| Normal Operating Temperature | ≤55ºC |
| Max. Operating Temperature | 80ºC(△P≤0.10Mpa) |
| Max. Differential Pressure | Normal Flow direction:4.2 bar at 25ºC, Reverse Flow direction: 2.1 bar at 25ºC |
| PH Value compatibility | 1-13 |
| Sterilizing temperature | Steam Sterilization for 30 minutes at 121±2ºC |
| Endotoxin | <0.25 EU/ml |
| Extractable | 0.03g/10" |
| Remark: special requirement of diameter and end caps can be customized |
| Complete test (minimum bubble point)(25ºC;95% isopropanol): |
| 0.10um | ≥0.024Mpa |
| 0.20um | ≥0.016Mpa |
| 0.45um | ≥0.012Mpa |
Shipping&Delivery
Delivery time: 1.If products is in stock, the lead time will be 1-3 days after payment.
2.If not in stock, the lead time will be about 7-15days after payment.
Contact us: JiAn city QingFeng Filter Equipment Co., Ltd ,located in new industrial park, QingYuan area, Ji'an Jiangxi Province, QingFeng Filter Equipment Material Co., Ltd is an ISO9001 certified company.
Since 2006,We focused on developing, producing and marketing micropore filter membrane,filter cartridge and filter housing.
We are a professional manufacturer who are developing, producing and marketing filter membrane, filter cartridge and filter housing,Filter bag for more than 30 years, We are the first factory who developed and produced the nylon reinforced microfiltration membrane (JN) and polyvinylidene fluoride reinforced microporous membrane(PVDF) in China
in 1994. All our products with ISO9001/SGS/FDA approved and shipped to all over the world, USA, Australia, England. Canada, Russia, Thailand, India....... Strictly inspected by advanced instrument before packing.Welcome to contact with us.
